Carpenter · Red Seal 403A
Five 403A practice test questions, answers included.
Five questions from five different work activities — recall and procedural, the way the exam is built. Pick an answer, then open the explanation. Every question in the bank explains all four options, not just the right one.
Free to read · No account · No email
50 free 403A questions in all
-
Where are the nails placed on a standard three-tab asphalt strip shingle, and how many are used in a normal-wind area?
- Four nails, in the headlap above the sealant strip, driven flush
- Six nails, below the sealant strip, heads set just under the surface
- Four nails per strip through the tabs, so they are sealed by the next course
- Four nails, below the sealant strip and above the cutouts, driven flush
Show the answer
D. Correct. The nail line is about 140 to 150 mm (5-1/2 to 6 in.) above the butt: below the sealant strip and about 16 mm (5/8 in.) above the top of the cutouts (the NBC minimum is 12 mm), one nail 25 to 40 mm in from each end and one above each cutout. Each nail then also holds the top of the course below. Nails are driven flush, not overdriven, and must penetrate the sheathing or go through it; six nails are used in high-wind areas.
Source: Red Seal Occupational Standard, sub-task E-15.02; National Building Code
-
An unused brick chimney that passes through the main floor, second floor and roof of a house is to be completely removed. What is the correct procedure?
- Cut it off just below the roof, roof over the hole and leave the rest
- Top down in large sections cut free with a masonry saw, lowered by rope
- Top down brick by brick, chuting debris, headering each opening as you pass
- Top down brick by brick, stacking the brick in the attic to lower out later
Show the answer
C. Correct. A chimney is freestanding and is taken down in the reverse of how it was built: from the cap downward, a course at a time, with the masonry chuted or bucketed out rather than dropped. As the work passes each level, the framing that was trimmed around the chimney is headered off with doubled members in hangers, and the roof hole is sheathed and roofed. Shore any floor framing that was resting on the chimney before the brick that supported it is removed.
Source: Red Seal Occupational Standard, sub-task G-22.02
-
A wall-mounted handrail on a stair must be graspable for its full length. What minimum clearance does the NBC require between the handrail and the wall?
- 25 mm (1 in.)
- 50 mm (2 in.)
- 75 mm (3 in.)
- 100 mm (4 in.)
Show the answer
B. Correct. NBC Part 9 requires at least 50 mm clearance between a handrail and the wall or any other surface behind it so the rail can be gripped along its length. Standard handrail brackets provide this when the rail is mounted on them; check if a thick profile or a tiled wall reduces it.
Source: Red Seal Occupational Standard, sub-task F-20.02; National Building Code
-
A 356 mm (14 in.) I-joist frames into an LVL header. The carpenter has a face-mount hanger sized for a 241 mm (9 1/2 in.) joist. How should the joist be hung?
- Use a hanger listed for the 356 mm joist depth, per the manufacturer
- Use the hanger as is and add an extra nail through the flange into the header
- Toe-nail the joist to the header with four 82 mm (3 1/4 in.) nails instead
- Notch the bottom of the joist so it sits in the smaller hanger
Show the answer
A. Correct. A hanger made for a 241 mm joist leaves the top of a 356 mm joist unsupported. Manufacturers require web stiffeners where the hanger sides do not reach and laterally support the top flange, and a hanger shorter than about 60 % of the joist depth also needs added restraint against joist rotation. Use the hanger the manufacturer lists for this joist and load, and fill every hanger hole with the specified nails.
Source: Red Seal Occupational Standard, sub-task D-10.01
-
Timber shoring is being installed in a 2.4 m (8 ft) deep excavation: vertical sheathing, horizontal walers and cross-trench struts. In what order should the members be installed as the crew works down from the top?
- Struts first, then walers, then sheathing
- Walers, then sheathing, then struts, working from the bottom up
- Sheathing, then walers, then struts, working from the top down
- Sheathing and struts together, adding walers only where the soil looks loose
Show the answer
C. Correct. Sheathing is placed tight to the excavation wall, walers are set against the sheathing, and struts or screw jacks are tightened between opposing walers. Installation proceeds from the top down so the upper soil is supported before workers go deeper; removal is the reverse, bottom up.
Source: Red Seal Occupational Standard, sub-task C-8.01
Want ten more with every option explained? Free 403A practice questions — no account, no email, printable. With five more on each exam block page below, that makes 50 free 403A questions in all.
The 403A exam at a glance
How many questions are on the 403A Red Seal exam?
The Red Seal Carpenter (403A) exam has 100 multiple-choice questions, a 4-hour writing time and a 70% pass mark, spread across seven major work activities. Between 75 and 85 percent are procedural questions: how to lay out, form, frame and finish. Sources: the Red Seal Program's exam information page and Exam Preparation Guide, checked October 21, 2026.
Question mix — weighted to the blueprint
The 403A is one of the most procedure-heavy Red Seal exams — the questions ask you to carry out a task the right way and in the right order. Recall-only question banks don't match the question mix the published exam breakdown sets.
The full 403A practice exam
Know your Carpenter score before exam day.
Free, Red Seal–style practice for the 403A Carpenter certification. Every test is weighted to the official exam blueprint — heavy on procedure — so your score shows where you stand on each part of the exam.
What the 403A covers
Seven major work activities.
The occupational standard groups the trade into seven major work activities, 22 tasks and 81 sub-tasks. The question counts below are the official blueprint weightings — our 550-question bank is built to that same map, with every sub-task covered.
- A
Common occupational skills · 12 questions
Tools and equipment, safety-related activities, temporary access structures such as scaffolds and ladders, communication and mentoring. Free block A questions: safety, tools and scaffolding →
- B
Planning and layout · 14 questions
Interpreting drawings and documentation, organizing work, and performing layout. Free block B questions: blueprints, takeoffs and layout →
- C
Concrete work · 16 questions
Constructing formwork and installing concrete, cement-based and epoxy products. Free block C questions: concrete and formwork →
- D
Framing · 20 questions
Floor systems, deck systems, wall systems, and roof and ceiling systems. Free block D questions: floor, wall and roof framing →
- E
Exterior finishing · 14 questions
Exterior doors and windows, roofing, and exterior finishes. Free block E questions: roofing, siding, windows and doors →
- F
Interior finishing · 14 questions
Wall and ceiling finishes, flooring, interior doors and windows, finish components and stairs. Free block F questions: interior finishing and stairs →
- G
Renovations · 10 questions
Renovation-specific support activities and renovation-specific construction. Free block G questions: renovation and demolition →
Where our numbers come from
Built to the published standard.
The question counts above are the Red Seal Program's own exam breakdown for Carpenter, and every question in our 550-question bank is mapped to a sub-task of the Red Seal Occupational Standard — 22 tasks and 81 sub-tasks, each one covered. When the standard is revised, we re-check the map and the weightings against it. For what each block covers and where to spend your study time, read the 403A exam guide. Read how our questions are made.
Edited by Trevor Mulder · Last checked against the Red Seal Program's published exam information.
Why practice scores mislead
You can ace recall and still fail the 403A.
Most question banks drill what you can recall, because recall questions are cheap to write. The 403A is overwhelmingly procedural — it asks you to carry out a task the right way, in the right order, to code. That gap is why people walk in confident and walk out surprised. TicketPrep weights every test to the published blueprint, so a weak section here is a weak section there.
How TicketPrep prepares you
Built like a study tool, not a quiz app.
Weighted to the blueprint
Every test matches the published 403A weightings — heavy on the procedural questions the published exam breakdown calls for.
Every answer explained
Learn why the right answer is right — and why each of the other three is wrong. That's where the learning happens.
Timed mock exams
Full-length tests that match the real 100-question count and 4-hour limit, so exam day feels familiar.
Know your weak areas
Your score broken out by work activity, so you always know which tasks to drill next.
